How to Configure Layer 3 Terminated VCs on the 4-Port ATM ISE Line Card
Committing a VC to a Bundle
To add a VC to an existing bundle and enter bundle-vc configuration mode, use the following command
in bundle configuration mode:
Command
Router(config-if-atm-bundle)# pvc-bundle pvc-name
[vpi/] [vci]
For information on how to create a bundle and configure it, see the
page 28
Applying Parameters to Individual VCs
Parameters can be applied to individual VCs either by using VC classes or by directly applying them to
the bundle members.
Parameters applied to an individual VC supersede bundle-level parameters. Parameters applied directly
to a VC take precedence over the same parameters applied within a class to the VC at the bundle-vc
configuration level.
The following should be noted regarding parameters applied to individual VCs:
•
•
The following sections describe applying parameters to individual VCs:
•
•
•
•
Configuring a VC Bundle Member Directly
Configuring VC bundle members directly is optional if a VC class is attached to the bundle member.
To configure an individual VC bundle member directly, use the following commands in bundle-vc
configuration mode:
Command
Router(config-if-atm-member)# bump {implicit |
explicit precedence-level | traffic}
Router(config-if-atm-member)# mpls experimental
[other | range]
Router(config-if-atm-member)# precedence [other |
range]
Cisco IOS Release 12.0(27)S
30
and the "Applying Bundle-Level Parameters" section on page
Policing in a policy-map is performed on the aggregate traffic of the bundle. In other words, policing
is not per VC, but rather for the whole subinterface.
MDRR defined using the bandwidth command is applied to each VC separately. In other words, the
weight of the MDRR will be relative to the traffic passing on each VC and not relative to the traffic
passing on the bundle.
Configuring a VC Bundle Member Directly, page 30
Configuring VC Class Parameters to Apply to a VC Bundle Member, page 31
Applying a VC Class to a Discrete VC Bundle Member, page 32
Configuring a VC Not to Accept Bumped Traffic, page 32
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
Purpose
Adds the specified VC to the bundle and enters bundle-vc
configuration mode to configure the specified VC bundle
member.
Purpose
Configures the bumping rules for the VC bundle member.
Specifies which MPLS experimental bit values can be mapped to
a member of a VC bundle.
Configures the precedence levels that apply to the VC bundle
member.
"Creating a VC Bundle" section on
28.
