Cisco ISE - Line Card ISE Configuration Manual page 24

How to Configure Layer 3 Terminated VCs on the 4-Port ATM ISE Line Card
In this task, use one of either
need to configure.
SUMMARY STEPS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
DETAILED STEPS
Command or Action
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
class match-any class-name
Example:
Router(config-pmap)# class match-any prec345
Step 4
match ip precedence numbers
Example:
Router(config-cmap)# match ip precedence 3 4 5
Cisco IOS Release 12.0(27)S
24
Step
enable
configure terminal
class-map class-map-name
match ip precedence numbers
exit
policy-map policy-name
class class-name
set atm-clp
set ip precedence value
set ip dscp ip-dscp-value
set mpls experimental value
set qos-group value
exit
exit
interface atmslot/port.subifnum
pvc vpi/vci
service-policy input policy-name
Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
8, Step 9, Step 10, Step 11, or
Purpose
Enables privileged EXEC mode.
Enter your password if prompted.
•
Enters global configuration mode.
Specifies the user-defined name of the traffic class. The
match-any keyword specifies a logical OR operator for all
matching statements under this traffic class.
Specifies up to eight IP precedence values used as match
criteria.
Step 12, depending on what bits you
