Software Configuration of ATM ISE Line Cards for Cisco 12000 Series Routers
DETAILED STEPS
Command or Action
Step 1
enable
Example:
Router> enable
Step 2
configure terminal
Example:
Router# configure terminal
Step 3
policy-map policy-map-name
Example:
Router(config)# policy-map out_cbr
Step 4
class class-default
Example:
Router(config-pmap)# class class-default
Step 5
queue-limit number-of-cells cells
Example:
Router(config-pmap-c)# queue-limit 200 cells
Step 6
exit
Example:
Router(config-pmap-c)# exit
Step 7
exit
Example:
Router(config-pmap)# exit
Step 8
interface atmslot/port
Example:
Router(config)# interface atm1/0
Step 9
atm clock internal
Example:
Router(config)# atm clock internal
Step 10
pvc [name] vpi/vci l2transport
Example:
Router(config-if)# pvc 21/21 l2transport
How to Configure AToM VCs on the 4-Port ATM ISE Line Card
Purpose
Enables privileged EXEC mode.
Enter your password if prompted.
•
Enters global configuration mode.
Specifies the name of the service policy to configure with
the shaping queue size.
Specifies to configure the default class.
Specifies or modifies the maximum number of cells the
queue can hold for a class policy configured in a policy
map.
Exits class mode.
Exits policy-map mode.
Specifies an ATM interface or subinterface to configure.
Causes the ATM interface to generate the transmit clock
internally.
Specifies a PVC with the specified VPI and virtual circuit
identifier (VCI). The l2transport keyword indicates that
the PVC is a switched PVC and not a terminated PVC.
Cisco IOS Release 12.0(27)S
51
