Installing a Catalyst 6509-NEB or Catalyst 6509-NEB-A Switch Chassis
Step 4 Install the standard cable guide to the back panel by securing the lip of the cable guide to the back panel.
(See Figure
Step 5 Install the two screws to secure the cable guide to the back plate. (See
Note
Attach the interface cables to the modules, and route the cables through the cable guide.
Step 6
Install the front panel by hooking the top of the front panel over the cable guide.
Step 7
Step 8 Tighten the two captive installation screws. (See
Figure 3-18
Catalyst 6500 Series Switches Installation Guide
3-34
3-17.)
Before installing the front panel, attach the interface cables to the modules, and route the cables
through the cable guide. See the
information on attaching the interface cables.
Front Panel Installation
FAN
STATU S
FAN
1
FAN
2
Captive installation screws
"Attaching the Interface Cables" section on page 3-61
Figure 3-18.)
Chapter 3 Installing the Switch
Figure 3-17.)
for
OL-5781-08
