Appendix A
Connector Pin Assignments
This appendix describes the system board connector pin assignments. Figure A-1 and
Figure A-2 show the locations of the system board connectors. Table A-1 identifies the
connector function with the connector number. Pin assignments for the connectors are
provided in the following subsections.
Diskette Drive
Connector
Keyboard and
Mouse Ports
Serial Ports
1 and 2
Parallel Port
Line Out Jack
Line In Jack
Microphone Jack
VGA Monitor
Port
Power SIMM
Connector Sockets
PCI/ISA Backboard
Connector
Figure A-1 System Board Layout
Primary IDE Secondary IDE
Connector Connector
Cache
Socket
See
Figure A-2
