NEC POWERMATE V Service Manual page 102

3-30 Option Installation
3. Identify the slot for the device being installed.
Remove the blank panel from the selected slot by pressing the panel tabs from
4.
inside the front panel and pushing the blank panel out (see Figure 3-30).
Remove the perforated metal plate from the selected slot on the chassis by pulling
5.
the metal plate back and forth until it releases.
Install the device (see Installing the Desktop 5 1/4-Inch Device).
6.
Front Panel
Figure 3-29 Removing the Front Panel
Top Blank
Panel Tabs
Bottom Blank
Panel Tabs
Figure 3-30 Locating the Blank Panel Tabs
Blank Panel
Tabs
(behind panel)
