Riser Board Specifications
The specifications for the riser board are included in the following table.
Feature
Design
Slots, Small Desktop
Slots, Desktop
Slots, Minitower
Industry Standard Interfaces
Keyboard Specifications
The specifications for the keyboard are included in the following table.
Feature
Keyboard
Dimensions
Weight
10-4 Specifications
Riser Board Specifications
Specification
NLX compatible
System board slot (170-pin edge connector)
Support for a total of four IDE devices; 40-pin connectors
1 PCI slot
1 shared PCI/ISA slot
2 PCI slots
1 shared PCI/ISA slot
1 ISA slot
3 PCI slots
2 ISA slots
Two PCI/IDE connectors (primary and secondary)
Diskette drive connector
Feature connector (power and signal to front control board)
CD Audio In connector
Modem In connector
Intrusion connector
Wake-On LAN connector
Fan connector
Power connectors
Keyboard Specifications
Specification
Chicony KB-8923
Width: 19.0 inches (48.3 cm)
Depth: 8.4 inches (21.3 cm)
Height: 1.6 inches (4.1 cm)
3.5 to 4.0 lb. (1.6 to 1.8 kg)
