PowerMate ES 5200 Series FRU List — Small Desktop
Item Description
21 Rear USB connector and cable assembly
22 Sound card, Creative Labs Sound Blaster
23a 56 Kbps Fax/modem US Robotics V.90 Python ISA board
23b 56 Kbps MDM100 Winmodem PCI board
24 3Com 10/100 Hurricane Ethernet network card with Wake-ON LAN
25 Chassis cover small desktop
26a Speakers, Altec Lansing 9 watt
26b Speakers, Harman Kardon 10 watt
27a Speaker AC adapter, Altec Lansing
27b Speaker AC adapter, Harman Kardon
28 Power supply, 145 watt
29 Internal hard drive bracket
30a 4.3-GB IDE 5400 RPM hard drive
30b 8.4-GB IDE 5400 RPM hard drive
30c 12.9-GB IDE 5200 RPM hard drive
30d 12.9-GB IDE 7200 RPM hard drive (as available)
31 Diskette drive, w/o bezel
32a 32X IDE CD-ROM, Lite-On
32b 32X IDE CD-ROM, NEC
32c 40X IDE CD-ROM, Lite-On
33 DVD-ROM
34 LS-120 cradle
35 LS-120 drive
36 Logo, "NEC PowerMate"
37 Front panel
38 Front panel PCB switch (includes Power & Sleep)
39 Fan assembly
40 Front USB port board and cable assembly
not shown Headset w/microphone (not shown)
not shown Tape cartridge (not shown)
not shown Zip disk (not shown)
not shown LS-120 diskette (not shown)
6-4 Illustrated Parts Breakdown
® ™
Live! PCI
