Removing System Board Rails Secured with Screws

Remove system board rails that are secured with screws by following these
steps.
1. Turn off the system and disconnect the system power cord.
2. Ensure that all external cables are disconnected from the front and rear of
the system.
3. Remove the system board.
T
For a small desktop system, see "Removing the System Board — Small
Desktop."
T
For a desktop system, see "Removing the System Board — Desktop."
T
For a minitower system, see "Removing the System Board —
Minitower."
4. Remove the two screws holding each rail to the system board (see the
following figure).
5. Lift the system board off the rails.
3-84 Disassembly and Reassembly

System Board Rails Secured with Screws
