SCOPE OPERATION (ADVANCED)
SCOPE SET screen
Waveform Color (Current)
(Default: (R) 217 (G) 241 (B) 247)
Sets the waveform color for the currently received
signals.
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to 255.
L The color is displayed in the box above the RGB scale.
Waveform Color (Line)
Sets the waveform outline color for the currently
received signals.
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to 255.
L The color is displayed in the box above the RGB scale.
Waveform Color (Max Hold)
(Default: (R) 58 (G) 110 (B) 147)
Sets the waveform color for the received signals
maximum level.
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to 255.
L The color is displayed in the box above the RGB scale.
Waterfall Display
Turns the Waterfall display ON or OFF for the Normal
scope and the Mini scope screens.
L On the Expanded scope screen, the Waterfall is always
displayed.
• OFF: Turns OFF the Waterfall display.
• ON: Turns ON the Waterfall display.
Waterfall Speed
Selects the Waterfall speed.
• Slow: Sets the Waterfall speed to Slow.
• Mid: Sets the Waterfall speed to Mid.
• Fast: Sets the Waterfall speed to Fast.
to adjust the level from 0
MULTI
(Default: (R) 70 (G) 30 (B) 0)
to adjust the level from 0
MULTI
to adjust the level from 0
MULTI
(Default: ON)
(Default: Mid)
Waterfall Size (Expand Screen)
Selects the Waterfall height in the Expand scope
screen.
• Small: The same height as the Normal scope
screen, only the FFT scope expands.
• Mid: The Waterfall height expands at the same
ratio as the FFT scope.
• Large: Only the Waterfall height expands.
Waterfall Peak Color Level
Selects the signal level that the Waterfall displays a
peak color.
Higher signal levels are Red, Yellow, Green, Light-
blue, Blue, and Black, in that order.
• Select between Grid 1 and Grid 10.
Waterfall Marker Auto-hide
Turns the Waterfall Marker Auto-hide function ON or
OFF.
• OFF: The marker in the Waterfall zone stays ON.
• ON: The marker in the Waterfall zone is hidden 2
seconds after it stops in place.
Dual Scope Type
When the Dual scope is selected, select the Main and
Sub scope layout.
• Over/Under: Displays the Main scope over the Sub
scope.
• Side by Side: Displays the Main and Sub scopes
side by side.
Dual Scope Auto Select
When the Dual scope is selected, by selecting the
band (Main or Sub) simultaneously switches the Main
or Sub scope.
• OFF: The Main scope and Sub scope are not
switched by selecting the Main band or Sub
band.
• ON: The Main scope and Sub scope are switched
by selecting the Main band or Sub band.
