Icom IC-7760 Advanced Manual page 106

11
OTHER FUNCTIONS
PRESET menu
You can save the combination of the following settings
for the data mode to quickly change the settings,
depending on your operating needs.
Preset Name
Mode
Filter
Filter BW
Filter Type (HF)
Filter Type (50M)
USB Output Select
USB AF Output Level
USB AF SQL
USB IF Output Level
USB MOD Level
DATA1 MOD
DATA2 MOD
L The transceiver has a total of 5 memories.
D Loading the preset memory
1. Open the PRESET screen.
» PRESET
MENU
2. Touch the preset memory to load.
(Example: 2: FT8)
3. Touch [YES].
• The selected preset memory is loaded, and "In Use"
is displayed on the PRESET screen. If you change
the transceiver settings, and they do not match the
contents of the preset memory, "In Use" disappears.
L Touching [UNLOAD] returns the transceiver settings
to those set before loading the preset memory.
NOTE:
• You cannot load the preset memory whose "Mode" is
checked while selecting a blank Memory channel in the
Memory mode.
• You cannot load a preset memory that is displayed as
"(BLANK)."
DATA3 MOD
SSB-D TX Bandwidth
DATA OFF MOD
COMP
SSB TBW
SSB TX Bandwidth
USB SEND
USB Keying (CW)
USB Keying (RTTY)
CI-V Address
CI-V Transceive
CI-V USB (A) Echo Back
D Editing the memory contents
NOTE: You cannot edit the preset memory that is in
use. To edit it, first touch [UNLOAD], and then edit
the memory.
1. On the PRESET screen, touch a preset memory
to edit for 1 second.
• Opens the QUICK MENU screen.
2. Touch "Edit the Preset Memory."
L When touching "Save to the Preset Memory," all of
the contents are set to the current settings before
editing.
3. Touch the check box to select whether or not to
load the item.
• "✓" is displayed on the left side of the loading item.
4. Touch the item name, and then touch the option
to set.
5. Repeat steps 3 and 4 to edit the preset memory.
6. Touch "<<Write>>."
7. Touch [YES].
TIP: Depending on your software, you may need to
change the "CI-V Address" setting.
For example, if you use a software that is not
compatible with the IC-7760, you may be able to use
the software by setting "CI-V Address" to another
transceiver's address.
11-8
