Icom IC-7760 Advanced Manual page 39

2
ADVANCED OPERATIONS
Operating PSK
D PSK DECODE SET screen
FFT Scope Averaging
Sets the FFT scope waveform averaging function to
between 2 and 4, or OFF.
L Use the default or smaller FFT scope waveform number
for tuning.
FFT Scope Waveform Color
Sets the waveform color for the FFT scope.
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to 255.
L The color is displayed in the box above the RGB scale.
AFC Range
Selects the Automatic Frequency Control (AFC)
function's operating range from ±15 Hz and ±8 Hz.
L The AFC function may not tune the signal properly when
a weak PSK signal is received.
Time Stamp
Selects whether or not to display the time stamp
(date, transmission time, and reception time) on the
PSK DECODE screen and to add it in the log.
• OFF: Does not display and add the time stamp.
• ON: Displays and adds the time stamp in the log.
Time Stamp (Time)
Selects whether to display the log on the PSK
DECODE screen and to save it with the local time or
with the CLOCK2's time.
Time Stamp (Frequency)
Selects whether or not to display the frequency on the
PSK DECODE screen and to save it in the log.
• OFF: Does not display and add the frequency.
• ON: Displays and adds the frequency in the log.
(Default: OFF)
(Default: R: 51, G: 153, B: 255)
to adjust the level from 0
MULTI
(Default: ±15 Hz)
(Default: ON)
(Default: Local)
(Default: ON)
Font Color (Receive)
Font Color (Transmit)
Font Color (Time Stamp)
Font Color (TX Buffer)
Sets the text font color for received, transmit, time
stamp, and TX buffer characters.
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to 255.
L The color is displayed in the box above the RGB scale.
2-29
(Default: R: 128, G: 255, B: 128)
(Default: R: 255, G: 106, B: 106)
(Default: R: 0, G: 155, B: 189)
(Default: R: 255, G: 255, B: 255)
to adjust the level from 0
MULTI
