Icom IC-7760 Advanced Manual page 31

2
ADVANCED OPERATIONS
Operating RTTY (FSK)
D RTTY DECODE SET screen
FFT Scope Averaging
Sets the FFT scope waveform averaging function to
between 2 and 4, or OFF.
L Use the default or smaller FFT scope waveform number
for tuning.
FFT Scope Waveform Color
Sets the waveform color for the FFT scope.
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to 255.
L The color is displayed in the box above the RGB scale.
Decode USOS
Turns the letter code decoding capability ON or OFF
after receiving a "space."
L USOS stands for UnShift On Space function.
• OFF: Decodes as a character code.
• ON: Decodes as a letter code.
Decode New Line Code
Selects the internal RTTY decoder new line code.
L CR stands for Carriage Return, and LF stands for Line
Feed.
• CR,LF,CR+LF: Makes a new line with any code.
• CR+LF: Makes a new line with only a
CR+LF code.
Diddle
Selects the diddle status code.
While transmitting in the RTTY mode, the selected
code is transmitted when there is no code to transmit.
• OFF: Turns OFF the Diddle function.
• BLANK: Transmits blank codes.
• LTRS: Transmits letter codes.
TX USOS
Explicitly inserts the FIGS character, even though it is
not required by the receiving station.
• OFF: Does not insert FIGS.
• ON: Inserts FIGS.
Auto CR+LF by TX
Selects whether or not to automatically send a new
line code (CR+LF) when transmitting.
• OFF: Does not transmit the CR+LF code.
• ON: Transmits a CR+LF code.
(Default: OFF)
(Default: R: 51, G: 153, B: 255)
to adjust the level from 0
MULTI
(Default: ON)
(Default: CR, LF, CR+LF)
(Default: BLANK)
(Default: ON)
(Default: ON)
Time Stamp
Selects whether or not to display the time stamp (date,
transmission time, and reception time) on the RTTY
DECODE screen and to add it in the log.
• OFF: Does not display and add the time stamp.
• ON: Displays and adds the time stamp in the log.
Time Stamp (Time)
Selects whether to display the log on the RTTY
DECODE screen and to save it with the local time or
with the CLOCK2's time.
Time Stamp (Frequency)
Selects whether or not to display the frequency on the
RTTY DECODE screen and to save it in the log.
• OFF: Does not display and add the frequency.
• ON: Displays and adds the frequency in the log.
Font Color (Receive)
Font Color (Transmit)
Font Color (Time Stamp)
Font Color (TX Buffer)
Sets the text font color for received, transmit, time
stamp, and TX buffer characters.
L Touch and select the R (Red), G (Green), or B (Blue)
scale, and then rotate
to 255.
L The color is displayed in the box above the RGB scale.
2-21
(Default: ON)
(Default: Local)
(Default: ON)
(Default: R: 128, G: 255, B: 128)
(Default: R: 255, G: 106, B: 106)
(Default: R: 0, G: 155, B: 189)
(Default: R: 255, G: 255, B: 255)
to adjust the level from 0
MULTI
