11. SD Card Slot

SD card is a very common storage device nowadays. The SD card that we have expanded
supports SPI mode. The SD card used is a MicroSD card. The schematic is shown in Figure
11-1.
SD card slot pin assignment:
Signal Name

12. LED

The board contains 4 user LED light-emitting diodes. The schematic diagram of the four
user LED is shown in Figure 12-1. When the pinout of the FPGA is logic 0, the LED goes out.
When the output is logic 1, the LED is lit.
17 / 23
Http://www.alinx.com.cn
SD_NCS
SD_DIN
SD_CLK
SD_DOUT
L4
L6 Line synchronization signal
N3 Field synchronization signal
Figure 11-1
SD Mode
AX301 User Manual
RED[4]
Pin
D11
F10
D12
E15
17 / 23
