Jasic EVOLVE 200 Operator's Manual page 48

EVOLVE 200
For DC TIG Pulse welding, set up as below ensure you place the machine in TIG pulse, HF ON and 2T trigger mode.
This multi icon bar shows the operator a quick view of TIG options and settings. The icons shown will change
depending on TIG background settings. Pressing the icons will allow entry to chosen setting.
TIG Mode Pulse Mode Manual Mode
Pressing the EXTRA icon will open up the advanced settings menu, from here you can select various additional TIG
options as shown in the below table.
UPSLOPE
PRE FLOW GAS
Rotating and pressing the left control dial will allow you to select, adjust and save TIG parameter settings.
You can also use the touch screen to navigate through and adjust settings as recommended below.
Parameter
Job/Material
HF Switch *
PRE-GAS TIME
START CURRENT
START CURRENT TIME
UP-SLOPE TIME
PEAK WELDING
CURRENT **
BASE CURRENT ***
PULSE FREQUENCY
PULSE WIDTH
DOWN-SLOPE TIME
FINAL CURRENT
FINAL CURRENT TIME
POST-GAS TIME
* Some of the above settings are accessed and adjusted from the Extra Menu as shown in the top image.
** Depends on material thickness (30A per mm) eg. 3mm = 90A
*** Set base current to 50% of your peak welding current
WELDING AMPS BACKGROUND AMPS
START AMPS & TIME PULSE FREQUENCY
Units Adjustable Range
---
N/A On or Off
Seconds 0.1 ~ 10
% (of peak) 20 ~ 150
Seconds 0 ~ 10
Seconds 0 ~ 10
Amps 5 ~ 200
Amps 5 ~ 200
Hz 0.5 ~ 200
% 10 ~ 90
Seconds 0 ~ 20
% (of peak) 20 ~ 80
Seconds 0 ~ 10
Seconds 0 ~ 15
TIG PULSE DC - Quick Set-Up Guide
2T Mode Extra Menu
PULSE WIDTH
FINAL AMPS & TIME
Guide Setting
--- ---
ON
0.5
20
0
0
User defined *
50% **
1
50
1
20
1
2
48
Set Accordingly
DOWN SLOPE
POST FLOW GAS
User Setting
