TROUBLESHOOTING - ERROR CODES
The following operation requires sufficient professional knowledge on electric aspects and
comprehensive safety knowledge. Make sure the input cable of the machine is disconnected
from the electricity supply and wait for 5 minutes before removing any machine covers.
The control display is also used for providing error messages to the user, if an error message is displayed,
the power source may only function to a limited capacity and the cause of the error should be checked
as soon as possible.
The below is a list of error codes for the Jasic Evolve range of welding machines, so some error codes may
not be applicable for certain models.
Error Code Error Meaning
Exceeding internal
1
voltage limits.
Backup voltage
2
failure.
High CPU
3
temperature.
Error in the unique
10
identifier.
11 Alarm 24V.
12 Alarm 5V.
13 Alarm -15V.
14 Alarm +15V.
15 Hall sensor.
Internal memory
17
failure.
Error in DC bus
18
voltage.
20 High probe voltage. Output voltage anomaly.
21 Unknown function.
Front panel display
22
error.
Error Description
Critical supply voltage in
the main control board.
Backup voltage failure.
The CPU temperature is
too high.
Error in the unique
identifier.
The power supply outside
the limits of 24V DC.
The power supply outside
the limits of 5V DC.
The power supply outside
the limits of -15V DC.
The power supply outside
the limits of +15V DC.
Anomaly in the read out
in the output current.
Memory anomaly.
Main inverter supply
voltage anomaly.
Selected program is not
available.
Front panel error.
Recommended Action
Restart the machine.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Power off the machine and
wait a few minutes to cool
down the CPU.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Restart the machine.
If the problem still exists then
contact the service centre.
Contact your dealer or login to
the JTE cloud to add additional
welding programs.
Restart the machine.
If the problem still exists then
contact the service centre.
108
Possible Cause
The main control board fault.
Low battery.
High ambient temperature.
Fault in the main control
PC Board.
Bad electrical connection.
Control PC board fault.
Supply PC board fault.
Control PC board fault.
Supply PC board fault.
Control PC board fault.
Supply PC board fault.
Control PC board fault.
Supply PC board fault.
Poor electrical connection.
Fault in the main control
board.
Problem with the machine
firmware.
Main power supply board
fault.
Main power supply fault
Fault in the main control
board.
N/A
Control PC board fault.
Front panel fault.
