Jasic EVOLVE 200 Operator's Manual page 47

EVOLVE 200
For DC TIG welding, set up as below, ensure you place the machine in TIG, HF ON and 2T trigger mode.
This multi icon bar shows the operator a quick view of TIG options and settings. The icons shown will change
depending on TIG background settings. Pressing the icons will allow entry to chosen setting.
TIG Mode Standard Mode Manual Mode
Pressing the EXTRA icon will open up the advanced settings menu, from here you can select various additional TIG
options as shown in the below table.
PRE FLOW GAS
Rotating and pressing the left control dial will allow you to select, adjust and save TIG parameter settings.
You can also use the touch screen to navigate through and adjust settings as recommended below.
Parameter
Job/Material
HF Switch *
PRE-GAS TIME
START CURRENT
START CURRENT TIME
UP-SLOPE TIME
PEAK WELDING
CURRENT **
DOWN-SLOPE TIME
FINAL CURRENT
FINAL CURRENT TIME
POST-GAS TIME
* Some of the above settings are accessed and adjusted from the Extra Menu as shown in the top image.
** Depends on material thickness (30A per mm) eg. 3mm = 90A.
UPSLOPE WELDING AMPS
START AMPS & TIME
Units Adjustable Range
--- ---
N/A On or Off
Seconds 0.1 ~ 10
% (of peak) 20 ~ 150
Seconds 0 ~ 10
Seconds 0 ~ 10
Amps 5 ~ 200
Seconds 0 ~ 20
% (of peak) 20 ~ 80
Seconds 0 ~ 10
Seconds 0 ~ 15
TIG DC - Quick Set-Up Guide
2T Mode Extra Menu
DOWN SLOPE
FINAL AMPS & TIME
Guide Setting
---
ON
0.5
20
0
0
User defined *
1
20
1
2
47
Set Accordingly
POST FLOW GAS
User Setting
