OPERATION - DOUBLE PULSE MIG
Before starting any welding activity ensure that you have suitable eye protection and
protective clothing. Also take the necessary steps to protect any persons within the welding
area.
MIG/MAG Pulse Welding Mode: (Continued)
Advanced Settings Menu
Start Force Mode:
Start force mode will offer an additional boost to initiating the welding arc
in pulse and double pulse MIG mode only by increasing the welding
voltage between 0 - 10%.
Pressing the Start Force option will open up the start force current
adjustment pop up box and by rotating the left control dial either
clockwise or anticlockwise you can adjust the setting from 0 to 10 %. You can also use the touch screen to
slide the bar to make the adjustment.
Once any adjustments are carried out, pressing the left control dial will automatically save, exit said
parameter and take you back to the previous screen.
Hot Start Mode:
Press the hot start icon to select turning ON or Off the Hot Start feature.
When Hot Start is ON (active), within the extra's setting (advanced settings
menu) you also have the option to turn on/off hot start but also you have
the options to adjust and set:
•
Start Current, adjustment range is 20 - 150%.
•
Start Timer, adjustment range is 0 - 10 seconds.
•
Start Slope adjustment range is 0 - 10 seconds.
When Hot Start is OFF, then Start Current, Start Timer and Start Slope are
'greyed' out and have a lock symbol next to them as shown right.
