The figure 3-11-4 detailed the J13 expansion port on the carrier board. The
Pin1 and Pin2 of the expansion port are already marked on the board.
Figure 3-11-4: Expansion header J13 on the carrier board
J13 Expansion Header Pin Assignment
Pin Number
1
3
5
7
9
11
13
15
17
19
21
23
25
27
29
31
33
35
37
39
53 / 59
ARTIX-7 FPGA Development Board AX7A035 User Manual
FPGA Pin
GND
W16
T15
GND
V14
W12
Y12
W10
AA10
AA9
U16
AA13
AB11
Y13
W14
Y16
AB16
AA15
GND
+3.3V
Pin Number
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
36
38
40
FPGA Pin
+5V
W15
T14
U15
V13
W11
Y11
V10
AA11
AB10
T16
AB13
AB12
AA14
Y14
AA16
AB17
AB15
GND
+3.3V
