Alinx AX7A035 User Manual page 27

ARTIX-7 FPGA Development Board AX7A035 User Manual
PIN27 B13_L10_N
PIN29 GND
PIN31 B13_L9_N
PIN33 B13_L9_P
PIN35 B13_L8_N
PIN37 B13_L8_P
PIN39 GND
PIN41 B14_L11_N
PIN43 B14_L11_P
PIN45 B14_L14_N
PIN47 B14_L14_P
PIN49 GND
PIN51 B14_L5_N
PIN53 B14_L5_P
PIN55 B14_L18_N
PIN57 B14_L18_P
PIN59 GND
PIN61 B13_L17_P
PIN63 B13_L17_N
PIN65 B14_L21_N
PIN67 B14_L21_P
PIN69 GND
PIN71 B14_L22_P
PIN73 B14_L22_N
PIN75 B14_L24_N
PIN77 B14_L24_P
PIN79 B14_IO0
The Pin1 of the connector has been marked with a dot on the board.
Figure 2-9-2: Board to Board Connectors CON2 on the Core Board
27 / 59
W10 3.3V
- Ground PIN30
AA11 3.3V
AA10 3.3V
AB10 3.3V
AA9 3.3V
- Ground PIN40
V20 3.3V
U20 3.3V
V19 3.3V
V18 3.3V
- Ground PIN50
R19 3.3V
P19 3.3V
U18 3.3V
U17 3.3V
- Ground PIN60
T16 3.3V
U16 3.3V
P17 3.3V
N17 3.3V
- Ground
3.3V
P15
3.3V
R16
3.3V
R17
3.3V
P16
P20 3.3V
PIN28 B14_L17_N
GND
PIN32 B14_L6_N
PIN34 B13_IO0
PIN36 B14_L7_N
PIN38 B14_L7_P
GND
PIN42 B14_L4_P
PIN44 B14_L4_N
PIN46 B14_L9_P
PIN48 B14_L9_N
GND
PIN52 B14_L12_N
PIN54 B14_L12_P
PIN56 B14_L13_N
PIN58 B14_L13_P
GND
PIN62 B14_L3_N
PIN64 B14_L3_P
PIN66 B14_L20_N
PIN68 B14_L20_P
PIN70 GND
PIN72 B14_L19_N
PIN74 B14_L19_P
PIN76 B14_L23_P
PIN78 B14_L23_N
PIN80 B14_IO25
AB18 3.3V
- Ground
T20 3.3V
Y17 3.3V
W22 3.3V
W21 3.3V
- Ground
T21 3.3V
U21 3.3V
Y21 3.3V
Y22 3.3V
- Ground
W20 3.3V
W19 3.3V
Y19 3.3V
Y18 3.3V
- Ground
V22 3.3V
U22 3.3V
T18 3.3V
R18 3.3V
- Ground
R14 3.3V
P14 3.3V
N13 3.3V
N14 3.3V
N15 3.3V
