Part 2.2: FPGA Chip

As mentioned above, the FPGA model we use is XC7A35T-2FGG484I,
which belongs to Xilinx's Artix-7 series. The speed grade is 2, and the
temperature grade is industry grade. This model is a FGG484 package with
484 pins. Xilinx ARTIX-7 FPGA chip naming rules as below
Figure 2-2-1: The Specific Chip Model Definition of ARTIX-7 Series
The main parameters of the FPGA chip XC7A35T are as follows
Logic Cells
CLB flip-flops
Block RAM（kb）
12 / 59
ARTIX-7 FPGA Development Board AX7A035 User Manual
Figure 2-2-2: FPGA chip on board
Name
Slices
Specific parameters
33,280
5,200
41,600
1,800
