Part 3.6: HDMI Input interface

HDMI output interface, select Silion Image's SIL9013/9011 HDMI decoder
chip, support up to 1080P@60Hz input and support data output in different
formats.
The IIC configuration interface of the SIL9013/9011 is connected to the IO
of the FPGA. The SIL9013 is initialized and controlled through FPGA
programming. The hardware connection of the HDMI input interface is shown in
Figure 3-6-1.
43 / 59
ARTIX-7 FPGA Development Board AX7A035 User Manual
9134_D[5]
9134_D[6]
9134_D[7]
9134_D[8]
9134_D[9]
9134_D[10]
9134_D[11]
9134_D[12]
9134_D[13]
9134_D[14]
9134_D[15]
9134_D[16]
9134_D[17]
9134_D[18]
9134_D[19]
9134_D[20]
9134_D[21]
9134_D[22]
9134_D[23]
HDMI_SCL
HDMI_SDA
Y21
U21
T21
W21
W22
T20
AB18
AA18
AA19
AB20
AA20
AA21
AB22
AB21
W17
V17
V20
U20
V19
H13
G13
