11 | Commissioning

11 Commissioning

11.1 First start-up

For the initial commissioning of your pellet stove you will be assisted by an authorised Austroflamm
service engineer. In the process he will show you the correct operation and the functions of the appli-
ance. He will also inform you of options for your stove, e.g. WLAN OPTION, wireless SMARTSPOT for
adjusting the desired room temperature.
The following settings are carried out during the initial commissioning.
Fig. 48: Fill pellets
Fig. 49: Start manual feed
Fig. 50: Start pellet stove
The stove body, many steel and cast iron parts and the flue pipes are painted with heat-resistant paint.
During the 1st start-up the paint is dried up by the ensuing temperature and in the process dries This
leads to the development of an odour. During this phase, please avoid touching the painted surfaces
and ensure that the room is well aired.
For a rapid hardening of the paint we recommend operating the stove on its initial commissioning for
3-4 hours at the highest output level.
76
EN
1) The pellet stove must be connected to the chimney.
Sufficient combustion air must be supplied.
2) Remove the accessories from the pellet hopper and
the firebox.
3) Fill the hopper with pellets and close the hopper lid.
NOTICE
In certain models a safety switch monitors the proper clos-
ing of the hopper lid and warns the user if it stays open.
4) Insert power cable and set tumbler switch on the back
of the hybrid stove to "I".
ð The Austroflamm logo will now appear on the dis-
play.
ð This is followed by the main operating level with
temperature displays and hopper level.
5) The pellet screw conveyor must be filled before the
first start-up.
ð To do this, go to Settings on the display and select
the "Manual feed" sub-item.
ð Hold "Feed" until the auger continuously feeds
pellets into the auger shaft.
ð The screw conveyor requires about 3 minutes to fill
up the screw shaft.
6) As soon as the first pellets fall into the combustion
pot, you can stop the manual filling.
7) After manually filling the screw, be sure to empty the
combustion pot of any pellets that have dropped into
it. After this you can start up your pellet stove.
8) To start the pellet stove, press "Start" on the display.
Operating manual Ruby 2.0
