Model: Kp-200, Measure Bar Assembly - Excel KP-200 Operation & Maintenance Manual

15-7 Model: KP-200
Model: KP-200
ITEM PART NO.
1 P-20404
2 W-20-08
3 P-20405
4 N-10-05
5 S-05-05
6 G-18-01
7 T-18-01
8 S-05-12
9 N-11-03
10 P-25402
11 S-05-09
12 P-25401
13 P-25403
14 P-25404-2
15 P-25404-1
16 S-04-14
Title: Measure Bar Assembly
Title: MEASURE BAR ASSEMBLY
DESCRIPTION
NUT
WASHER
LENGH FIXED ROD
NUT
HEX HEAD CAP SCREW
STELLNESS MEASURE
RIVIT
HEX SOCKET CAP SCREW
NUT
MEASURE BAR HOLDER
HEX SOCKET CAP SCREW
MEASURE BAR
FRAME
HANDLE
FIXED SCREW
"+" ROUND HEAD SCREW
Drawing No.: M-092007
Drawing No.: M-092007
SPECIFICATIO
Ø 14.5
M8*1.25
M8*1.25*30
14*0.5*450
Ø 2.1*6
M8*1.25*30
3/4"-16 UNC
M8*1.25*16
M6*1.0*10
85
Q'TY
1
1
1
1
1
1
3
1
1
1
3
1
1
1
1
2
