Excel KP-200 Operation & Maintenance Manual page 89

Model: KP-200
ITEM PART NO.
1 OH-06-01
2 OB-60-01
3 P-25318
4 OC-62-01
5 OH-06-02
6 S-04-04
7 SW-30-04
8 OB-60-02
9 P-12-06
10 HO-13-02
11 HO-13-01
12 P-25317
13 SB-50-01
14 P-25319
15 P-25320
16 P-25321
17 P-25323
18 SO-35-04
19 P-25322
20 SO-35-02
21 P-25325
22 S-05-15
23 S-04-09
24 P-25324
25 P-25316
26 SB-50-04
Title: PRESSURE ADJUSTABLE ASSEMBLY
DESCRIPTION
OIL HOSE
"L" SQUARE ELBOW
OIL TANK
FLUG
OIL HOSE
HEX SOCKET CAP SCREW
SPRING WASHER
SQUARE ELBOW
ELBOW
HYDRAULIC HOSE
HYDRAULIC HOSE
OIL PRESSURE BLOCK
STEEL BALL
BALL HOLDER
+ SLEEVE
SPRING
ADJUSTABLE SLEEVE
O-RING
PRESSURE ADJUSTABLE SCREW
O-RING
DIAL
SOCKET SET SCREW
HEX SOCKET CAP SCREW
FLANGE
PLATE
STEEL BALL
SPECIFICATIO
6*4.6*108
1/8"PT*5.5
1/2"HT*32*6
6*4.6*110
M6*1.2*2.0
Ø 6.5
1/8"*5.5
1/4"PT*3/8"HT
3/8"HT*500mm
3/8"HT*650mm
5/8"
P-22A
P-12
M8*1.25*10
M6*1.0*12
Ø3/8"
83
Drawing No: M-092005
Q'TY
1
3
1
1
1
4
4
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
