Chapter 2. Structure and Appearance of Machine

2-1. Performance and Function

2-1-1. Specification
CUTTING CAPACITY ●
CUTTING CAPACITY ▀(H*W)
MAX. CUTTING DEGREE/DIA.
DISTANCE OF STROKE
STROKES PER. MIN.
BLADE SIZE
MAIN MOTOR
MEASUREMENT (L*W*H)
NET WEIGHT
GROSS WEIGHT
Grease gun 100G
17mm*19mm Open end wrench
6*100mm "+" Screw driver
300mm Adjustable wrench
11mm*13mm Open end wrench
Handle
M16*2.0*45 Head cap screw
M14*2.0*70 Head cap screw
Ø 14 Washer
MODEL
Particular tools list
Name
UNIT
mm
mm
N。/mm
mm
times
mm
HP(KW)
mm
kg
kg
Quantity Name
1 4mm "L" Hexagon head
1 5mm "L" Hexagon head
1 6mm "L" Hexagon head
1 8mm "L" Hexagon head
1 Measure bar
1 Pressure bar
4 Balance bar
2 Material rack
2 Tool box
5
KP-200
200
190*190
45。/90
120
105 . 125
350*32*1.6*8.3
1 (0.75)
1240*730*1010
270
330
Quantity
1
1
1
1
1
1
1
1
1
