ITEM 5 d
Malfunction
Oil level of pressure adjusting value decreases abnormally
Cause
d. Oil seal or O ring on top cover of cylinder and piston bar
Trouble shooting
d. Replace O ring of P-28, or UPH 28*43*10 of oil seal, in the event two seals
requiring replacements, a dust seal of 36*28*6T must be replaced together as
following illustration:
Remark
d. Repaired by qualified technician, dismantled parts must be placed in clean
place. Replenish oil after replacement, refer the manual instruction
1 Big Piston Bar
2 Top Cover of Cylinder
3 C Clasp RTW-43 4 Dust Seal 36*28*6
5 O Ring P-22A
6 Oil Seal UPH 28*43*10
7 O Ring KP-200 /G105
60
