Excel KP-200 Operation & Maintenance Manual page 81

Model: KP-200
ITEM PART NO.
1 P-25130-2
2 P-25130-1
3 S-08-01
4 W-20-08
5 P-25127
6 S-07-01
7 P-25135
8 S-07-02
9 P-20103
10 P-25112
11 P-20104
12 S-04-14
13 P-20129
14 P-20131
15 S-04-09
16 N-10-04
17 N-11-03
18 P-25110
19 P-20102
20 P-20132
21 P-20119
22 S-04-03
23 S-04-05
24 P-25109
25 S-04-04
26 P-20107
27 P-25108
28 P-20111
29 P-25105
30 P-25106
31 N-10-11
Title: VISE ASSEMBLY
DESCRIPTION
TURN HANDLE
TURN HANDLE SCREW
HEX HEAD CAP SCREW
WASHER
PIN
HEX SOCKET CAP SCREW
WASHER
HEX HEAD CAP SCREW
JAW (REAR)
FIXED PLATE
SCREW ROD
"+" ROUND HEAD SCREW
FIXTURE
PUSH-RING
HEX HEAD CAP SCREW
NUT
NUT
WASHER
JAW (FRONT)
EQUILIBRIUM ROD
EQUILIBRIUM ROD PIN
HEX SOCKET CAP SCREW
HEX SOCKET CAP SCREW
SCREW ROD FLANGE
HEX SOCKET CAP SCREW
VISE SCREW
HANDLE
SCREW ROD PROTECTOR COVER
SLIDE BLOCK (FRONT)
SLIDE BLOCK (REAR)
NUT
Drawing No.: M-092002
SPECIFICATION
M14*2.0*70
Ø 14.5
M12*1.75*45
Ø 12.5*Ø 32*5
M12*1.75*50
M6*1.0*10
M6*1.0*12
M6*1.0
3/4"-16UNC
M6*1.0*12
M6*1.0*25
M6*1.0*20
M20*2.5
75
Q'TY
1
1
2
2
2
1
1
1
1
1
2
2
1
1
1
1
4
3
1
1
1
2
1
1
3
1
1
1
1
1
1
