Noise In Chin Head - Excel KP-200 Operation & Maintenance Manual

ITEM 1 c
Malfunction
Cause
Trouble shooting
Remark

12-2. Noise in Chin Head

ITEM 2 a
Malfunction
Cause
Trouble shooting
Remark
ITEM 2 b
Malfunction
Cause
Trouble shooting
Remark
ITEM 2 c
Malfunction
Cause
Trouble shooting
Remark
Insufficient Sawing Pressure
c. Fatigue spring of pressure adjustment
Pressure Adjusting
1
Knob
Pressure Adjusting
4
Screw
Steel Ball/Sphere
7
Contact
Replace the pressure adjusting spring
c. Repaired by qualified technician, or contact local dealer/producer for prompt
service
Noise in Chin Head
a. Lack of lubrication oil
a. Replenish lubrication oil according to manual instruction
a. Use MOBILITH AW3 oil
Noise in Chin Head
b. Gear Damage
b. Dismantle the slider and saw frame, check the big and small gears, replace the
gears damaged if necessary
Caution : refer to manual instruction to dismantle the parts
b. Repaired by qualified technician or contact local dealer/producer for prompt
service
Noise in Chin Head
c. Damage or wear/tear to bearing
c. Replace the bearing as per manual instruction
c. Repaired by qualified technician or contact local/producer for prompt service
2 Scale 3 Pressure Adjusting Spring
Steel Ball
5 6
Washer
8 Steel Ball 9 High Pressure Hose
○
3
56
Ring of Pressure Adjusting
Spring
