2-1-2. KP-200 Dimensions
1. Dimensions of various sections (scale: mm)
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
640 840 65 535 330 80 415 1200 355 380 995 995 425 565 440 300 350
2. Dimensions of Material Rack (scale: mm)
A
B
C
D
E
F
300 380 320 265 370 290
