Excel KP-200 Operation & Maintenance Manual page 50

9-2-2. Procedure of Replacing Hydraulic Oil
a. Firstly dismantle the right side protection cover as following drawing
Right Side
Protection Cover
Table (1)
ITEM NAME
1 Stopper
2 Waste oil tank
1. Firstly prepare a proper waste oil tank, reference as table (2)
2. Release the stopper with proper wrench
○
leaking of oil 2
○
3. Remove stopper
1
4. After the pouring, restore the stopper tightly
5. Transfer the waste oil into a big oil container to prevent pollution
Waste oil tank
○
1
, let the waste oil pour into oil tank
ITEM
○
1
○
2
○
3
Table (2)
Model KP-200
1.8L
, before removing the stopper, put a container below to avoid
○
, place the stopper at a clean place
2
NAME
Waste oil tank
funnel
Waste oil container
