Excel KP-200 Operation & Maintenance Manual page 78

Model: KP-200 Title: MACHINE BODY ASSEMBLY
ITEM PART NO.
1 N-10-04
2 P-25137
3 N-10-02
4 P-25119
5 LM-18-02
6 W-20-04
7 S-04-03
8 S-02-02
9 P-20121
10 W-20-06
11 UN-50-02
12 P-25120-1
13 P-25120-2
14 N-10-06
15 HE-20-01
16 EH-19-01
17 N-10-05
18 SW-30-05
19 S-05-08
20 P-20227
21 V-20-09
22 KY-15-06
23 MT-10-04
24 P-25123
25 S-06-03
26 GR-25-01
27 HW-14-01
28 LM-18-01
29 WH-30-01
30 S-05-04
31 W-20-05
32 P-11-04
33 HW-14-02
34 P-25126
35 S-04-04
36 WM-28-01
37 P-11-02
38 HD-80-02
39 P-20133-1
DESCRIPTION
NUT
PULLEY SIDE COVER
NUT
MICRO SWITCH HOLDER
MICRO SWITCH
WASHER
HEX HEAD CAP SCREW
"+" ROUND HEAD SCREW
PULLEY COVER
WASHER
HANDLE
PULLEY COVER STRUT SCREW
PULLEY COVER STRUT SCREW
NUT
PVC UNION
HOSE
NUT
SPRING WASHER
SOCKET SET SCREW
MOTOR PULLEY
V-BELT
KEY
MOTOR
MOTOR PLATE
HEX SOCKET CAP SCREW
HANGER
COOLANT PIPE
MICRO SWITCH
PIPE
HEX HEAD CAP SCREW
WASHER
TWO-HEAD PIPE
VALVE
ELECTRIC BOX
HEX SOCKET CAP SCREW
COOLANT PUMP
JOINT
HANDLE
COVER
Drawing No: M-092001
SPECIFICATION
M6*1.0
M4*0.5
TM1703
Ø 6*12*0.6
M6*1.0*12
M4*0.5*30
Ø 10.5*Ø 25*1.5
M10*1.5*25*50
M10*1.5
3/8"
3/8"
M8*1.25
Ø 8.5
M8*1.25*12
A-43
8*8*35
1HP-3PH-50HZ
M10*1.5*40
5/8"
1/4"PT*460
TZ-7310
Ø 14*18*315
M8*1.25*25
Ø 8.5*20*1.5
1/4"PT*1/4"PT*70
1/4"PT*1/4"PT
M6*1.0*20
1/8HP
3/8"PT*Ø14
SK-63-8
72
Q'TY
4
1
4
2
1
9
4
4
1
1
1
1
1
5
4
2
8
8
1
1
1
1
1
1
1
1
1
1
1
4
4
1
1
1
6
1
2
2
1
