12-3. Insufficient Lifting Height of Saw Frame after Sawing Job

ITEM 3 a
Malfunction
Cause
Trouble shooting
Remark
ITEM 3 b
Malfunction
Cause
Trouble shooting
Remark
ITEM 3 c
Malfunction
Cause
Trouble shooting
Remark
Insufficient lifting height of saw frame after sawing job
a. Fatigue spring of cylinder
a. 1. Refer to ITEM 1 b 1 to replace the fatigue spring
2. The spring force is big, use mechanical lift to dismantle the parts to
avoid danger
1 Tube Head of
Spring
3 Fixing Screw of
Piston Bar
5 Spring Tube
1. Repaired by qualified technician
2. Must use mechanical tool to avoid flying out of spring
cause injury
3. Contact local dealer/producer for repair
Insufficient lifting height of saw frame after sawing job
b. Check if any obstacle inside
b. Remove the obstacle inside
Turn off power before checking
Insufficient lifting height of saw frame after sawing job
c. Consistency between timer scale and the lifting height
c. Check the timer scale-second
The scale is from 0 to 10 seconds
2 Tool to press spring tube (inner diameter must
be bigger than piston bar)
4 Spring of Cylinder
6 Cylinder
58
Use mechanical lift
to remove the spring
to avoid danger
Clean surface
○
,
which may
