Excel KP-200 Operation & Maintenance Manual page 83

Model: KP-200
ITEM PART NO.
1 P-20211
2 BR-29-32
3 BR-29-24
4 GR-70-01
5 P-20202
6 BR-29-23
7 BR-29-07
8 P-20106
9 SW-03-05
10 P-20225
11 S-05-04
12 P-20217
13 KY-15-04
14 S-05-11
15 P-25138
16 S-05-15
17 P-20212
18 KI-16-04
19 S-02-02
20 P-25119
21 LM-18-01
22 N-10-02
23 W-20-04
24 S-04-09
25 S-06-07
26 SW-03-06
27 P-25316
28 S-05-09
29 P-25122
30 SW-03-04
31 S-04-05
32 N-10-05
33 P-20215
34 RT-34-05
35 BR-29-03
36 BR-29-34
37 BR29-27
38 P-20213
39 BR-29-15
Title: SAW FRAME ASSEMBLY
DESCRIPTION
GEAR SHAFT
ROLLER BEARING
BALL BEARING
GREASE NIPPLE
SAW FRAME HEAD
BALL BEARING
BALL BEARING
BEARING COVER
SPRING WASHER
PULLEY SPACER
HEX HEAD CAP SCREW
DRIVE PULLEY
KEY
HEX HEAD CAP SCREW
WASHER
SOCKET SET SCREW
GEAR SHAFT SLEEVE
PIN
"+" ROUND HEAD SCREW
LIMIT SWITCH HOLDER
LIMIT SWITCH
NUT
WASHER
HEX HEAD CAP SCREW
HEX SOCKET CAP SCREW
SPRING WASHER
OIL PRESSURE BLOCK
HEX SOCKET CAP SCREW
LIMIT SWITCH TOUCH HOLDER
SPRING WASHER
HEX SOCKET CAP SCREW
NUT
ECCENTRIC SHAFT SLEEVE
C-SNAP RING
BALL BEARING
ROLLER BEARING
BALL BEARING
ECCENTRIC SHAFT
BALL BEARING
Drawing No.: M-092003
SPECIFICATION
RNA-6904
6010Z
GR-K 1/8"PT
6009ZZ
6204ZZ
Ø 8.5
M8*1.25*25
5*5*25
M8*1.25*25
M8*1.25*10
Ø 6*35
M4*0.5*30
IZ-7310
M4*0.5
Ø 6.5
M6*1.0*12
M10*1.5*35
Ø 10.5
M8*1.25*16
Ø 6.5
M6*1.0*25
M8*1.25
STW-17
6203Z
RNA-4905
16007
6207
77
Q'TY
1
1
1
3
1
1
1
1
5
1
3
1
1
1
1
2
1
2
2
1
1
2
2
2
4
4
1
2
1
2
2
1
1
4
1
1
1
1
1
