Excel KP-200 Operation & Maintenance Manual page 19

Instruction of protective cover (shield) of big belt wheel:
No. Item
1 Auxiliary inner shield
2 Inner shield
3 Fixing screw of inner shield
4 Support screw of main
shield
5 Fixing screw of main
6 Main shield
7 Washer
8 Fixing bolt of main shield
Application
To prevent hands injury of person
To prevent hands/hair/clothes from
pulling in
To fix the inner shield
To support and guide the main
shield
To support and guide the main
shield
To prevent hands/hair/clothes from
pulling in
To fix the bolt and nut of main shield When shifting the sawing
To fix the main shield securely
13
When to dismantle
Do not dismantle
Do not dismantle
Do not dismantle
Do not dismantle
Do not dismantle
When shifting the sawing
speed
speed
When shifting the sawing
speed
