12-4. Tilt under Proper Pressure

ITEM 4 a
Malfunction
Cause
Trouble shooting
Remark
ITEM 4 b
Malfunction
Cause
Trouble shooting
Remark

12-5. Oil Level of Pressure Adjusting Value Decreases Abnormally

ITEM 5 a
Malfunction
Cause
Trouble shooting
Remark
ITEM 5 b
Malfunction
Cause
Trouble shooting
Remark
ITEM 5 c
Malfunction
Cause
Trouble shooting
Remark
Tilt under proper pressure
a. Wear/tear of blade, incorrect teeth
a. Replace damaged blade with proper teeth
Refer to manual instruction to replace the parts
Tilt under proper pressure
b. Insufficient blade tension
b. Use tension meter to adjust to proper tension
Refer to manual instruction to adjust proper tension
Oil level of pressure adjusting value decreases abnormally
a. Leaking of oil hose or connector
a. Replace the pipe or connector if damaged
a. Refer to manual to repair, or contact dealer/producer to supply parts
Oil level of pressure adjusting value decreases abnormally
b. Damaged or deteriorated O ring or in the valve
b. Replace O ring, type :P-12 or P-22A
b. Replenish hydraulic oil, type: MOBIL DTE Light 32#
Oil level of pressure adjusting value decreases abnormally
c. Damaged or deteriorated O ring on the top or bottom of cylinder
c. Check the O rings on top or bottom covers, replace the ring, type:
(KP-200) G105, ensure the O ring placed into the trough without
outstanding part
c. Refer to drawing 5 d to replace the part
