Excel KP-200 Operation & Maintenance Manual page 86

Model: KP-200
ITEM PART NO.
1 P-20327
2 S-0404
3 S-10-01
4 P-20312
5 P-20311
6 S-04-05
7 P-20303
8 SO-35-05
9 SO-35-09
10 SE-32-01
11 RT-34-01
12 P-25309
13 TA-33-03
14 SO-35-06
15 P-20304
16 P-20305
17 SO-35-03
18 SE-32-02
19 RT-34-02
20 TA-33-06
21 P-20306
22 P-20307
23 P-20308
24 P-12-15
25 IK-26-02
26 P-20310
27 SB-50-02
28 KT-20-01
29 S-04-03
30 P-25314
31 BR-29-21
32 P-20301
33 P-12-11
34 P-12-04
35 P-20302
36 S-04-07
37 SO-35-01
38 AD-21-01
39 S-04-06
Title: CYCLINDER ASSEMBLY
DESCRIPTION
SMALL PISTON TOUCH SHAFT
HEX SOCKET CAP SCREW
HEX SOCKET CAP SCREW
SLEEVE
SPRING
HEX SOCKET CAP SCREW
TOP CAP
O-RING
O-RING
OIL SEAL
C-SNAP RING
NUT
BIG PISTON RING
O-RING
BIG PISTON
BIG PISTON ROD
O-RING
OIL SEAL
C-SNAP RING
PISTON RING
SMALL PISTON
SPRING
PISTON COVER
"L" SQUARE ELBOW
DUST SEAL
SPRING
STEEL BALL
PIN
HEX SOCKET CAP SCREW
BEARING COVER
BALL BEARING
CYLINDER
"L" SQUARE ELBOW
CORK HOLDER
BOTTOM CAP
HEX SOCKET CAP SCREW
O-RING
VALVE BODY
HEX SOCKET CAP SCREW
Drawing No.: M-092004
SPECIFICATIO
M6*1.0*20
M6*1.0*10
M6*1.0*25
P-28
G-105
UPH-28*43*10
RTW-43
100*3.0*3.5
P-90
P-15
UPH-15*25*8
RTW-25
F.S.Ø 51*2.5*2.2
3/8"PT*3/8"HT
RYD-28*35*5/6
Ø7/16"
Ø 3*23
M6*1.0*16
6006ZZ
1/4"PT*3/8"HT
1/4" PT
M6*1.0*55
P-9
AD-8C
M6*1.0*30
80
Q'TY
1
3
3
1
1
10
1
1
2
1
1
1
2
1
1
1
2
1
1
2
1
1
1
1
1
3
3
2
6
2
2
1
1
1
1
4
3
1
2
