3.6.2.1 Selected level of assistance indicator
The higher the selected level of assistance, the
more the drive system assists with pedalling.
eMTB mode is available for Performance Line CX
drives. In eMTB mode, the assistance factor and
the torque are dynamically adjusted depending on
the pedalling force applied to the pedals.
Level of assistance Colour
OFF No
ECO Green
TOU R blue
e
Purple
M TB /SP ORT
TU RB O Red
Table 17: Overview of level of assistance
3.6.2.2 ABS indicator (optional)
The ABS indicator lights up on pedelecs with an
ABS system when they start up.
The ABS will switch off if the pedelec reaches a
speed of 6 km/h.
If there is a fault, the ABS indicator lights up
together with the indicator of the selected level of
assistance, which will flash orange.
Press the Select button to acknowledge the fault
and the flashing indicator for the selected level of
assistance will go out. The ABS indicator remains
lit to indicate that the ABS system is not in
operation.
MY23I0a - 42_1.0_22.01.2024
Use
When the drive system is
switched on, the motor
assistance is switched off.
Use the pedelec like a
normal pedelec by simply
pedalling
Limited assistance with
maximum efficiency for
maximum range
Constant assistance, for
long-range tours
Powerful assistance, for
sporty start-up, optimal
assistance on all types of
terrain
Maximum assistance up to
high pedalling frequencies,
for sport riding
3.6.2.3 Battery level indicator (on-board com-
puter)
The battery level indicator (on-board computer)
shows the battery charge level. You can also see
the battery charge level on the LEDs on the
battery itself.
Each blue bar on the indicator signals 20%
capacity and each white bar 10% capacity. The
top bar indicates maximum capacity. The two
lower indicators will change colour if the capacity
is low:
Flash sequence
Description
Capacity
90 ... 100%
80 ... 89%
70 ... 79%
