In the event of a hazard, a protective circuit
switches the battery off automatically. In the event
of a hazard, a protective circuit switches the
battery off automatically.
The battery has a high energy content when
charged. The code of practice for their safe
handling is found in Section 2 Safety and
Section 6.9 Rechargeable battery in the operating
instructions. If the electric drive system is not used
for 10 minutes and no button has been pressed on
the on-board computer or the control panel, the
electric drive system and the battery are
automatically switched off to save energy.
The type and duration of operating conditions
have a significant effect on the battery life. Just
like any other lithium-ion battery, the battery will
age naturally if it is not being used. The battery's
service life can be extended if the battery is well
maintained and stored at the correct temperature.
The charging capacity will decrease with age,
even if the battery is maintained properly. If the
operating time is severely shortened after
charging, this is a sign that battery has reached
the end of its useful life.
Battery performance is reduced when the
temperature drops since this increases electrical
resistance. You should expect the range to be
less than normal at low temperatures in winter.
We recommend using thermal protection sleeves
when riding longer distances at low temperatures.
Each battery has its own lock.
The following battery can be built into the pedelec:
PowerPack 545
Figure 49: Overview of battery variants
MY23I0a - 42_1.0_22.01.2024
PowerPack 725
4
5
6
10
Figure 50: PowerPack details
1
Battery level indicator (battery)
1
Securing hook
2
On-Off button (battery)
3
Battery housing
4
Top mount
5
Battery lock
6
Battery key
7
Retainer guard
8
Charging socket cover
9
Socket for charger plug
10
Lower mount
Description
2
1
3
7
8
9
74
