3.5.1.8 Components and repair parts for XXL RE 14 ZR F
J-02
Frame
Rear frame damper
Tyres
Front | Rear
Tube
Front | Rear
Wheel
Rim
Front | Rear
Spoke
Front | Rear
Spoke nipples
Front | Rear
Front wheel hub
Rear wheel hub
Steering headset
Stem
Handlebars
Handles/tapered
Left hand | Right hand
Fork
Fork remote control
Saddle
Seat post
Saddle clamp
Pedal
Crank set
Chain/belt
Chain wheel/belt sprocket
Chain guard
Chain guide
Motor
On-board computer
Display
Control panel
MY23I0a - 42_1.0_22.01.2024
Original i:SY Compact, 47 cm, unisex
...
SCHWALBE, Pick up
SCHWALBE, AV7
...
RYDE, Andra 40 Disc
Stainless steel
#
SHIMANO, DEORE HB-M6000-QR
ROHLOFF Speedhub 500/14
i:SY headset
i:SY, stem
BY,SCHULZ, Speedlifter Twist
i:SY, handlebars
ERGON, GP10
i:SY fork
...
VELO ENTERPRISE, #
#
#
i:SY anti-slip folding pedal
i:SY e-bike crank
GATES, CDX
#
HORN, Catena
...
BOSCH™, Performance Line CX (BDU3740)
BOSCH™, LED Remote (BRC3600)
BOSCH™, Kiox 300 (BHU3600)
Display mount (BDS3YYY)
...
Aluminium, 47 cm
...
Size: 60-406 (20"),
See Section 3.5.11
40/62-406
See Section 3.5.12
...
32H
32 units, 2.0 mm
#
Front wheel hub, 36H; see Section 3.5.10
Gear hub, 14-speed; see Section 3.5.10
#
70 mm
Tool-free handlebar height adjustment
Twist function: twist ± 90°
Handlebar clamp: Ø 31.8 mm
T22
30°, 630 mm
Winged grips
Rigid fork, aluminium (AL6066/CR-MO)
Head tube:1 1/2" - 1 1/4" x 450 mm
Crown, diameter: 62 mm
Fork clearance: 295 mm
...
ZECURE, #
i:SY seat post
#
...
Length: 170 mm
Toothed belt
#
...
...
See Section 3.6.7
See Section 3.6.5
See Section 3.6.6
See Section 3.6.7
...
