3.5.1.6 Components and repair parts for N3.8 ZR CX COMFORT
H-06
Frame
Tyres
Tube variants
Rim band
Rim
Spoke
Spoke nipples
Front wheel hub
Rear wheel hub
Steering headset
Stem
Handlebars
Handles/tapered
Fork
Saddle
Seat post
Saddle clamp
Pedal
Crank set
Chain/belt
Chain wheel/belt sprocket
Chain guard
Sprocket/belt sprocket/
freewheel variant
Shifter
Motor
On-board computer
Display
Rechargeable battery
Charger
MY23I0a - 42_1.0_22.01.2024
HAOJIE, i:SY E5 ZR F Century
SCHWALBE, SCHWALBE Pick-Up
SCHWALBE, AV7 + AP
SCHWALBE, AV7D Downhill (20")
TAPIR, 6781
RYDE, Andra 40
MACH1, Plus
SAPIM, Polyax
SHIMANO, DEORE HB-M6000
ENVIOLO, CVP-TR-32-DC
HAOJIE, GH-236
BY,SCHULZ, Speedlifter Twist Pro SDS
SATORI, Noirette
ERGON, GC1
i:SY
VELO CYCLE, ZECURE VL-6546 XL COMF
BY,SCHULZ, G.2 ST
HAOJIE
i:SY, folding pedal
#, Magan 4 (110058)
GATES®, 120T CDX (11M-120T-12C)
GATES®, BOSCH GEN4 Spider unit CDX
HORN, Catena A08/38
GATES®, 22T ENVIOLO CDX (CT1122VMN)
GATES®, 22T ENVIOLO CDX (XF1122E9MN)
ENVIOLO, Twist Display Pro (MC-TWIST-DISP-
PRO)
BOSCH, Performance Line CX/Cargo
[BDU3740](EB11.100.001)
BOSCH, LED Remote [BRC3600] (BRC3600)
BOSCH, Kiox 500 [BHU3700] (EB13.100.004)
BOSCH, PowerPack Frame 545 [BBP3550]
(EB12.100.02J)
BOSCH, 4A charger [BPC3400] (EB12.110.001)
Aluminium, 47 cm
# Size: ETRTO 65-406 (#), version: Super Defense
Valve: AV; valve length: 40 mm; size: ETRTO 47/
75-470; version: Downhill
Valve: AV; valve length: 40 mm; size: ETRTO 54/
75-406; version: Downhill
Size: 8 mm × 2000 mm; thickness: 0.30 mm,
colour: Yellow
14G, 32H
14G, Ø: 2 mm; length: 179 mm; see Section #
14G, Ø: 2 mm; length: 138 mm; see Section #
Inside Ø: 14G; length: 14 mm
32H; see Section #
Gear hub, continuously variable, 36H; see
Section #
# ZS56/31.8|/ 40
# Height-adjustable stem; #extension height:
170 mm (T17); #stem length: 55 mm; see
Section #
Length: 630; rise: 40 mm; backsweep: 45°; see
Section #
Winged grips, NEXUS
Rigid fork, shaft length: 300 mm
# Size: XL COMF
Parallelogram seat post, Ø: 34.9 mm; length:
400 mm; see Section #
...
Folding pedal; see Section #
Crank length: 160 mm, ISIS
# Belt, polyurethane/carbon; pitch: 11, number of
teeth: 120; width: 12 mm; length: 1320 mm
Belt sprocket, 55T
Plastic, #129203
Belt sprocket, 22T
Belt sprocket, 22T
Twist grip shifter with indicator; see Section #
See Section 3.5.06.1
See Section #
See Section #
#
Charging current (max.): 4 A, 220-240 V; see
charger instructions
