3.5.3.5 SR SUNTOUR cartridge LO
2. 2.
Figure 23: LO operating elements
MY23I0a - 42_1.0_22.01.2024
The SR Suntour LO cartridge features
•
a compression damper
•
a rebound damper
Before riding, use the rebound adjuster (fork) (1)
to adjust the system to the surface you will ride on.
You can use the compression adjuster (2) remote
control to open and close the damping.
If the pressure in the fork is too high, the blow-off
feature releases air by opening a valve. This
prevents any damage due to overpressure.
Compression
damping
Rebound
damping
Table 15: An overview of SR SUNTOUR LO functions
1 1
Lockout remote control
Fork head lockout
High-speed
Low-speed
Fixed
High-speed
Low-speed
Fixed
Blow-off feature
PCS
Description
Function
available
...
x
...
...
x
...
...
x
x
...
59
