Bosch i:SY E5 ZR F CX Translation Of Original Operating Instructions page 233

SR SUNTOUR
Damping side, top, aluminium
SR SUNTOUR
Damping side, bottom,
without adjuster
SR SUNTOUR
Damping side, bottom, with
adjuster
SR SUNTOUR
Fork head clamps
SRAM RockShox, 35
Cover cap
SRAM RockShox, Lyrik,
ZEB
Compression damper cover
cap
SRAM RockShox, Lyrik,
ZEB
DebonAir+ suspension cover
cap
SRAM RockShox, Lyrik,
ZEB
Dual Position air suspension
cover cap
SRAM RockShox, 35
Attachment screw –
compression adjustment ring
and remote operation ring
SRAM RockShox, Lyrik,
ZEB
Attachment screw –
compression adjuster
Charger RC (Select)
SRAM RockShox, Lyrik,
ZEB
Attachment screw –
compression adjustment ring
Charger RC (Select)
SRAM RockShox, 35
Attachment screw –
deflection adjustment ring
(Dual Position Coil)
SRAM RockShox, Lyrik,
ZEB
ButterCup housing guide rod
end plate - end plate to guide
rod - air suspension and
damper
SRAM RockShox, Lyrik,
ZEB
ButterCup housing (top) to
ButterCup housing (bottom) –
air suspension and damper
SRAM RockShox
Bottomless Tokens
SRAM RockShox, Lyrik,
ZEB
Sealing head (rebound) for
damper cartridge barrel cover
cap – Charger RC (Select),
Rush RC (Base)
SRAM RockShox, Lyrik,
ZEB
Pressure relief valve (PRV)
and stopper
MY23I0a - 42_1.0_22.01.2024
20 Nm
10 Nm
7 Nm
7 Nm
28 Nm
RockShox cover cap/cassette tool (or standard
28 Nm
RockShox cover cap/cassette tool (or standard
28 Nm
28 Nm
1.4 Nm
1.35 Nm
0.75 ... 1.1 Nm
1.35 Nm
3.3 Nm
3.3 Nm
4 Nm
2 Nm
9 Nm
Description
socket nut, 24 mm
cassette tool)
cassette tool)
socket nut, 24 mm
2.5 mm hex bit
2.5 mm hex bit
2.5 mm hex bit
2.5 mm hex bit
Torx® T25
23 mm spanner head
8 mm socket nut and 24 mm hex bit
10 mm socket nut
19 mm spanner head
