6.4.13.1 Adjusting the SR Suntour rear frame damper sag
Only applies to pedelecs with this equipment
Every rear frame damper has a specific delivery
air pressure ex works. These levels are starting
points. These settings can be changed based on
riding skills, trail conditions, frame design and
personal preferences.
Pressure
...
Factory reset
Maximum
...
pressure
Table 31: Suntour rear frame damper filling pressure table
Adjusting the suspension fork sag (see
Section 6.4.12).
The compression lever is set to OPEN.
1 Remove air valve cap from the air valve (rear
frame damper).
2 Attach a high-pressure damper pump to the air
valve (rear frame damper).
3 Pump the rear frame damper to the required
pressure. Never exceed the recommended
maximum air pressure from the Suntour rear
frame damper filling pressure table (see
Table 31).
Notice
If the air pressure in the rear frame damper is
exceeded or undershot, the damper can be
permanently damaged.
4 Remove high-pressure damper pump from the
air valve (rear frame damper).
MY23I0a - 42_1.0_22.01.2024
Recommended air pressure [psi]
200
180
180
250
300
240
After setting up the rear frame damper, check the
sag to ensure that the recommended settings are
observed.
180
200
110
300
240
300
5 Apply force on the saddle to compress the rear
frame damper several times by at least 50% of
the full deflection.
This equalises the air pressure between
positive and negative air chambers.
6 Measure the gap between the air chamber seal
and the end of the rear frame damper. This gap
is the total deflection (rear frame damper).
Operation
110
110
110
300
300
300
139
