Once the lock function is switched on, the pedelec
can only be put into use if:
•
the configured smartphone is switched on,
•
the smartphone is charged sufficiently and
•
the smartphone is directly next to the control
panel.
If the key is not immediately verified on the
smartphone, the battery level indicator and the
display of selected level of assistance on the
pedelec flash white to indicate a search for the
key.
If the key is found, the battery level indicator
flashes white. The last configured level of
assistance is displayed. If the key cannot be found
on the smartphone, the pedelec drive system
switches off. The indicators on the control panel
go off.
As the smartphone is only used as a contactless
key to switch on the pedelec, the battery and
control panel can still be used on another,
unblocked pedelec.
6.4.15.6 Inserting the display
1 Place display (1) on the locking hook (2) on the
front edge of display mount (3) facing the
direction of travel.
2 Press display rear onto the display mount.
1
I
2
3
Figure 136: Inserting the display
MY23I0a - 42_1.0_22.01.2024
II
6.4.15.7 Securing the on-board computer
(optional)
It is possible to secure the on-board computer so
that it cannot be removed. The locking plate does
not offer theft detection.
2
Figure 137: Position of headset screw
1 Insert locking plate (3) into the adapter tray (2)
until you hear the locking plate lock into
position.
The display mount (1) can now only be
removed if the two attachment screws (4) are
undone.
6.4.15.8 Removing the on-board computer
The on-board computer can be removed if it is
not secured.
1
2
Figure 138: Removing the on-board computer
Pull display (1) forwards until the display is
lifted from the display mount (2).
Operation
1
4
3
145
