Bosch i:SY E5 ZR F CX Translation Of Original Operating Instructions page 30

Sprocket/belt sprocket/
freewheel variant
Shifter
Motor
On-board computer
Display
Battery variant
Charger
Brake variant 1
Brake variant 2
Brake disc variant 1
Brake disc variant 2
Headlight variant
Rear light
Reflectors, rear
Reflectors on side
Pannier rack, rear
Guard variant
Stand
Bell/horn variant
Battery lock variant
... not available
# Information not available when document was produced
MY23I0a - 42_1.0_22.01.2024
SHIMANO, CS-HG500-10 (12-28T)
SHIMANO, CS-HG50-10 (11-36T)
SHIMANO, CUES SL-U6000-10R
SHIMANO, DEORE SL-T6000-R
SHIMANO, TIAGRA SL-4700
BOSCH, Performance Line CX/Cargo
[BDU3740](EB11.100.001)
BOSCH, LED Remote [BRC3600] (BRC3600)
BOSCH, Kiox 300 [BHU3600] (EB13.100.003)
BOSCH, PowerPack 600 [BBP3560]
(EB12.100.00M)
BOSCH, PowerPack Frame 545 [BBP3550]
(EB12.100.02J)
BOSCH, 4A charger [BPC3400] (EB12.110.001)
SHIMANO, BL-MT402-3A/BR-MT410
TEKTRO, # HD-T532
SHIMANO, RT-EM300
SHIMANO, SM-RT54
TEKTRO, TR-45
TEKTRO, TR-45
FUXON, FF-100 EB-HB
FUXON, FF-100 HB/FFB-70
FUXON, R-Glow
COMUS, FZR-006
BUSCH&MÜLLER, 309
HAOJIE, HJ11CA12-21-03 (QC-A186AA)
SKS, PET A65 R275 20"
SKS, PET A65 R275 20"
PLETSCHER, Comp 40
NUVO ENTERPRISE, n+1 B508AP
WIDEK, e-bike
ABUS, BLO
ABUS, DT3
Cassette, 10-speed, 12-13-14-15-17-19-21-23-25-
28T (12-28T); see Section #
Cassette, 10-speed, 11-13-15-17-19-21-24-28-32-
36T (bk); see Section # (11-36T); see Section #
Shifter with indicator, 10-speed
Shifter with indicator, 10-speed
Shifter with indicator, 10-speed
See Section 3.5.06.1
See Section #
See Section #
#
#
Charging current (max.): 4 A, 220-240 V; see
charger instructions
3-finger brake lever | Length: 1700 mm | Hydraulic
disc brake, 2-piston
3-finger brake lever | Length: 1100 mm | Hydraulic
disc brake, 2-piston
3-finger brake lever | Length: 1200 mm | Hydraulic
disc brake, 2-piston
# 3-finger brake lever | Length: 1200 mm |
Hydraulic disc brake, 2-piston
# 3-finger brake lever | Length: 1800 mm |
Hydraulic disc brake, 2-piston
Ø: 160 mm
Ø: 160 mm
Ø: 180 mm
Ø: 160 mm
Light cable length: 1300 mm; remote control cable:
1200 mm; see Section #
Light cable length: 1100 mm; remote control cable:
850 mm; see Section #
Bolt distance: 50 mm; see Section #
#
Spoke reflectors
Drawing: HJ11CA12-21-03 (QC-A186AA)
Drawing: 6744-790
Drawing: 6774-7907
Kickstand
Bell, aluminium with plastic base. Bell cover
diameter: 42 mm
Bell
...
...
Documents
30
