- Page 1 INSTALLATION BOSCH 3.07 VERSION ENGINES ACTIVE LINE PERFOMACE LINE PERFOMACE LINE CX...
-
Page 2: Installation
Remove the batter y from e-bike Looking at the bike from behind, on the left side (opposite side to the chainring), remove the 3 Torx screws (T20) that hold the protective cap of the Bosch engine (in this case Performance CX). - Page 3 After removing the protective cover, identify the two plugs of the display (the second connector from left of 4 wires colored: yellow-green-black-red) and the speed sensor (2 wire plug fully right: black-red). With a long forceps carefully remove the two plugs paying attention not to pinch them ruining plugs or wires.
-
Page 4: Not Covered By Warranty
Insert the thermoshrinking sheath (enclosed) in the two disconnected wires, pushing it over the plug. Insert plugs (output cables from chip) their respective sockets (cables disconnected from the engine) respecting the correct wire color: DISPLAY PLUG > YELLOW-YELLOW / GREEN-GREEN / BLACK-BLACK / RED-RED AND SPEED SENSOR PLUG >... - Page 5 SPEED SENSOR HMI (DISPLAY) PLUG PLUG SPEED SENSOR HMI (DISPLAY) SOCKET SOCKET TO THE DISPLAY (HMI) PLUG: TO THE SPEED RED => RED SENSOR PLUG: BLACK => BLACK GREEN => GREEN BLACK => BLACK YELLOW => YELLOW RED => WHITE (SEE PHOTO 5) (SEE PHOTO 5) 5.
- Page 6 Carefully cover the two plugs with shrink wrap and with a hair dryer or a lighter heat uniformly the sheath (turning it from right to left) until you have the sheath that takes the shape of the plugs. Be careful not to burn wires or plugs. 6.
- Page 7 RED WIRE TO RIGHT WHITE WIRE TO RIGHT Now connect the two plugs remaining on the chip to the engine, respecting the correct posi- tion of the colors (display RED WIRE and speed sensor WHITE WIRE get to the RIGHT) and push the connectors firmly to the end;...
-
Page 8: Racing Mode
RACING MODE ACTIVATION OF THE SPEED UNLOCK The engine unlock at 25 km / h is activated by pressing the Walk button on the on-board computer. The activation button can be changed (see pag. 9). The display will show the value 2.2 if the unlock has been activated and 1.1 if it is deactivated. - Page 9 [0.5] > For INTUVIAvisualization of total km done; for PURION/NYON the partial and total km will be visible asusual on the display; • parameter [1.5] > Display Type (only Bosch) 1.1 Purion/Nyon (default) 2.2 Intuvia; 3.3 Nyon • parameter [2.5] > Choice of wheel circumference size: •...
-
Page 10: Factory Settings
FACTORY SETTINGS YOUTUBE VIDEO: https://youtu.be/qr_QfI5uDdc • parameter [4.5] > Automatic calibration of wheel circumference: If the bike is stopped, the message 55.6 will appear on the display for a few seconds, at the end of calibration 50.1 appears. If the bike is moving or the magnet on the spokes is positioned above the sensor, calibration is NOT STARTED and 99.9 appears on the display;... - Page 11 APP E PLUS Only for Advanced version It is necessary to download our application Eplus smart controller, available for: Android / iOs Android http://goo.gl/DehnLE http://goo.gl/i3uwvL We recommend reading the manual of our Eplus smart controller application, back to the manual section: https://www.eplus.bike/en/guides/ 11.
- Page 12 12 months warranty. We are responsible for manufacturing defects and not for installation defects. Do not expose to moisture and sources of heat.
