3.5.9.7 Lighting
Lighting includes:
• The front light (also known as the headlight or
front lamp)
• The rear light (also known as the rear lamp)
The headlight and the rear light are also on
whenever the riding light is activated.
3.5.9.8 FUXON front light, FS-100 EB main beam with main beam switch
The FUXON front light, FS-100 EB main beam
features a reflector and a main beam switch.
Figure 53: Parts of FUXON, FS-100 EB main beam
1 Headlight
2 Main beam switch
3 Reflector
In normal mode, the headlight illuminates the road
ahead with around 100 lux. The LED in the main
beam switch lights up green in normal mode.
You can turn on the main beam by pressing the
main beam switch briefly. Press on it again briefly
to turn the headlight back to normal mode.
The LED in the main beam switch lights up blue in
main beam mode.
MY23I0a - 42_1.0_22.01.2024
1
2
3
The provisions in road traffic regulations apply to
main beam operation.
• The main beam must not be activated in built-up
areas or on roads with consistently adequate
lighting at any time.
• The main beam must not be used the moment it
may dazzle other road users.
