Adjusting preload internally
1 Release all the air from the main reservoir.
2 Remove the O-ring from beneath the air
chamber.
3 Rotate the high-pressure cuff (high volume)
and press downwards.
4 Add or remove the required quantity of volume
spacers.
Add air volume spacer.
Adding air volume spacers creates a more
progressive sensation when riding. A more
progressive sensation prevents rough
bottoming-out and stops the damper from
remaining low in the deflection range.
Remove air volume spacer.
Removing air volume spacers creates a
stronger, linear sensation when riding. It helps
to remove the air volume spacers if the full
deflection cannot be achieved or the rear frame
damper becomes very hard at the end of the
travel.
5 Push high-pressure cuff upwards and tighten.
The air reservoir is air-tight.
6 Attach O-ring.
MY23I0a - 42_1.0_22.01.2024
Operation
141
