3.5.1.5 Components and repair parts for E5 ZR F CX MY i:SY
H-05
Frame
Tyres
Tube
Rim band
Rim
Spoke
Spoke nipples
Front wheel hub
Rear wheel hub
Steering headset
Stem
Handlebars
Handles/tapered
Fork
Saddle
Seat post
Saddle clamp
Pedal
Crank set
Chain/belt
Chain wheel/belt sprocket
Chain guard
Sprocket/belt sprocket/
freewheel
Shifter
Motor
On-board computer
Display
Rechargeable battery
Charger
Front brake
MY23I0a - 42_1.0_22.01.2024
HAOJIE, i:SY E5 ZR F Century
SCHWALBE, SCHWALBE Pick-Up
SCHWALBE, AV7 (20")
TAPIR, 6781
RYDE, Andra 40
MACH1, Plus
SAPIM, Polyax
SHIMANO, DEORE HB-M6000
SHIMANO, NEXUS SG-C7000-5D
HAOJIE, GH-236
BY,SCHULZ, Speedlifter Twist
SATORI, TDS-D507G-8FOV
SATORI, Roxetta
ERGON, GC1
i:SY
VELO CYCLE, ZECURE VL-6483 L
SATORI, Camber (SP-387)
HAOJIE
i:SY, folding pedal
#, Magan 4 (110058)
GATES®, 118T CDX (11M-118T-12CT)
GATES®, BOSCH GEN4 Spider unit CDX
HORN, Catena A08/38
GATES®, SHIMANO Inter-5E SF 6L combined
(CT1128YMN-U)
SHIMANO, NEXUS SL-C7000-5
BOSCH, Performance Line CX/Cargo
[BDU3740](EB11.100.001)
BOSCH, LED Remote [BRC3600] (BRC3600)
BOSCH, Kiox 500 [BHU3700] (EB13.100.004)
BOSCH, PowerPack Frame 545 [BBP3550]
(EB12.100.02J)
BOSCH, 4A charger [BPC3400] (EB12.110.001)
TEKTRO, # HD-T532
Aluminium, 47 cm
Size: ETRTO 60-406 (20 × 2.35 inches), version:
Super Defense; see Section #
Valve: AV; valve length: 40 mm; size: ETRTO 40/
62-406; version: Standard
Size: 8 mm × 2000 mm; thickness: 0.30 mm,
colour: Yellow
14G, 32H
14G, Ø: 2 mm; length: 179 mm; see Section #
14G, Ø: 2 mm; length: 152 mm; see Section #
Inside Ø: 14G; length: 14 mm
32H; see Section #
Mechanical gear hub, 5-speed, 32H
# ZS56/31.8|/ 40
# Stem extension, #extension height: 220 mm
(T22); shaft Ø: # mm; reducing sleeve height:
# mm; see Section #
# Ø: 31.8 mm; extension: 70 mm; see Section #
Length: 660, see Section #
Winged grips, NEXUS
Rigid fork, shaft length: 300 mm
# Size: L
Patent seat post, Ø: 34.9 mm; length: 415 mm; see
Section #
...
Folding pedal; see Section #
Crank length: 160 mm, ISIS
# Belt, polyurethane/carbon; pitch: 11, number of
teeth: 118; width: 12 mm; length: # mm
Belt sprocket, 46T
Plastic, #129203
Belt sprocket, 28T
Twist grip shifter with indicator, 5-speed; see
Section #
See Section 3.5.06.1
See Section #
See Section #
#
Charging current (max.): 4 A, 220-240 V; see
charger instructions
# 3-finger brake lever | Length: 1200 mm |
Hydraulic disc brake, 2-piston
